EPLAN Cable proD
Software for efficient machine cabling

EPLAN Cable proD
Software for efficient machine cabling

EPLAN Cable proD is a solution for quick and easy cabling of machines. The software digitises the corresponding designs and provides the information required for production and assembly. This means that prefabricated cables can also be used.


Cable planning based on the plug & play principle

Precision is required when constructing machines – all the way through to the final steps: if the cables don’t have the correct lengths or have been incorrectly routed, it is not uncommon for entire commissioning processes to have to be postponed.

EPLAN has therefore dedicated an entire software solution for planning the corresponding machine cabling: EPLAN Cable proD. This also makes it easy to order prefabricated cables. Time-consuming trimming and offcuts are now a thing of the past.

This is how you benefit from EPLAN Cable proD

Morate omogućiti funkcionalne kolačiće da biste prikazali ovaj videozapis.

Determine cable lengths early on

The routing path and thus the length of the cable is determined on the digital model of the machine during the engineering phase, meaning that the space required for cabling has already been determined at this early stage of the process.

Morate omogućiti funkcionalne kolačiće da biste prikazali ovaj videozapis.

Include different disciplines

The requirements for the electrical engineering are visualised in the MCAD model, thereby ensuring that the cables can be installed as planned.

cable prod bill of material

Easier ordering

Ordering the proper prefabricated cables is made easier because all the information has been collected in one place. The engineering results include the length along with the exact routing and connection assignments.

Morate omogućiti funkcionalne kolačiće da biste prikazali ovaj videozapis.

Secure planning

Early coordination between mechanical and electrical engineering allows for good planning, meaning that any “unpleasant surprises” – like those due to errors that are only first recognised in assembly – are a thing of the past.

Morate omogućiti funkcionalne kolačiće da biste prikazali ovaj videozapis.

Faster assembly

The digital twin provides important information for the mounting of the cables. The digital model is also used for coordinated planning. Any changes required at short notice remain the exception and schedules can be easily adhered to.

First glimpse of machine cabling with EPLAN Cable proD

Combine EPLAN Cable proD with additional solutions

These products add even more value:

EPLAN Electric P8

The schematics: basic information for machine cabling

The schematics generated in EPLAN Electric P8 supply the cable and device data, thus all the basic information required for machine cabling. Transfer this data to EPLAN Cable proD and define the cabling virtually on the 3D model of the machine.

EPLAN Pro Panel

Also design the control cabinet in 3D

Follow a consistent path to digitalisation for control cabinet design as well. In EPLAN Pro Panel, you can create a complete 3D model of the control cabinet and this digital twin can be used to supply all the data and information for manufacturing the control cabinet.

Design cable pathways in 3D

Read more about how EPLAN makes machine cabling better and easier with EPLAN Cable proD.

Do you have challenges in engineering and manufacturing of machines?

Learn more about automated engineering and machine wiring.

We are happy to help!

Please contact us if you’d like to learn more about EPLAN Cable proD. We’re looking forward to helping you.
